Pressure loading valves PLV
Pressure loading valves PLV maintain a constant counterpressure for the dosing pump. They are used in the following
applications:
• Too low counterpressure or no counterpressure at all
• Fluctuating system pressure with outlet-side pulsation damper
• To prevent syphoning, when the inlet pressure is higher than the counterpressure
Pressure loading valves are installed in the outlet line.
Pressure loading valves should not be used as shut-off valves.
Loading pressure:
• factory-set to 3 bar approximately
• adjustable from 1 to 5 bar
Max. operating pressure: 16 bar
Max. flow rate: 60 l/h
• The flow rate values apply to liquids with a viscosity similar to waterHose connection set: 4/6 mm, 6/9 mm, 6/12 mm, 9/12 mm
Pipe connection set (Stainless steelDiaphragm: PTFE-coated
